NEUTRIK NP2RX-B Mono Right Angle 1/4 Inch Plug with Gold Contacts & Black Shell

1/4" professional right-angle phone plug, 2 pole, nickel contacts, nickel shell. The heavy-duty professional phone plug series improves on the design of the existing C series by offering the thinnest available A-gauge 1/4" plug with unique Neutrik chuck type strain relief on the market. The slimline shell with a width of 14.5 mm meets the most recent requirements for highest density jack fields (15.88mm jack pitch). The precise machined one-piece tip contact without rivets makes it unique and avoids hook up in a socket or break off the tip. The Plug X Series serves all applications such as guitar applications, audio cables, snakes, speakers, amplifiers and mixing desks.

Features:

• All metal housing eliminates the plastic cover of the predecessor NP*RCS and improves further durability and EMI protection Extra slim 1/4" plug for highest packing density Robust diecast shell in stylish design Proven chuck type strain relief for reliable cable retention Sleek design for best handling convenience Precision machined one-piece contacts - avoid hook up of tip contact

Specifications:

• Gender: Male
• Connection Type: Plug
• Contact Resistance: Depends on mating connector mΩ
• Dielectric Strength: 1kVdc
• Insulation Resistance: > 2GΩ (initial)
• Rated Current per Contact: Depends on mating connector A
• Rated Voltage: < 50V
• Cable O.D.: 4 - 7mm
• Lifetime: >1000 mating cycles
• Wire size(mm/AWG): 1mm²/18AWG
• Wiring: Solder contacts
• Bushing: Polyacetal (POM) + PU
• Contact Plating: 0.2µm Au
• Contacts: Brass (CuZn39Pb3)
• Insert: Polyamide (PA 6.6 30% GR)
• Shell: Zinc diecast (ZnAl4Cu1)
• Shell Plating: KTL coating
• Strain Relief: Polyacetal (POM)
• Standard Compliance: IEC 60603-11/EIA RS-453
• Solderability: Complies with IEC 68-2-20
• Temperature Range: -4°F - 149°F (-20°C - 65°C)
